- Forward path receiver
- Wavelength: 1550nm
- Bandwidth: 54/85/105 to 862/1002 MHz (customerized)
- RF output level: 108dBuV TYP. for FTTB and 108dBuV min for FTTCurb
- RF output ports: 1~2 for FTTB and 2~4 for FTTCurb
- RF output level with AGC over wide optical input power range, up to 10dBm
- Equalizer: 0~15dB
- Attenuation: 0~15dB
- Return path transmitter
- Wavelength: 1610±10nm or 1310±50nm (customerized)
- Bandwidth: 5 to 42/65/85 MHz (customerized)
- Output power: +3dBm TYP., DFB LD
- NPR Dynamic Range @ 30dB NPR: 15dB min
- Burst mode LD operation
Other benefits
- PON WDM is available (1310&1490nm / 1550&1610nm)
- Multiple diplexer filter options
- Redundancy for forward and return path
- Local power feeding or Remote power feeding
- User friendly fiber management
